PRODUCT PARAMETER
| MECHANICAL SPECIFICATION of Poly solar panel | ||
| Format | 1650*991*35mm | 1960mm x 991mm x 40mm |
| Weight | 18kg ±3% | 23kg ±3% |
| Cell | 6 x 10 monocrystalline cells | 6 x 12 monocrystalline cells |
| Junction Box | Protection class IP67 | |
| Cable | 4mm² Solar cable | |
| Connector | MC4 Compatible | |
| ELECTRICAL CHARACTERISTICS | |||||
| Minimum performance at standard test conditions,stc1 (power tolerance 0-3%) | |||||
| Power Class | [W] | 310 | 380 | 385 | |
| Power at MPP2 | PMPP | [W] | 310 | 380 | 385 |
| Short Circuit | ISC | [A] | 9.81 | 10.05 | 10.11 |
| Open Circuit | VOC | [V] | 40.1 | 48.71 | 48.98 |
| Current at MPP* | IMPP | [A] | 9.15 | 9.5 | 9.58 |
| Voltage at MPP* | IMPP | [V] | 32.8 | 40.3 | 40.29 |
