Parameter
| MECHANICAL SPECIFICATION | |||
| Format | 1676*994*6mm | ||
| Weight | 23.3kg±3% | ||
| Cell | 60(6 x 10) polycrystalline cells | ||
| Junction Box | Protection class IP67, with bypass diodes | ||
| Cable | 4mm² Solar cable | ||
| Connector | MC4 Compatible | ||
YE(280-320)M60
描述
| ELECTRICAL CHARACTERISTICS | |||
| minimum performance at standard test conditions,stc1 (power tolerance -0~+5w) | |||
| Model | 315W | 320W | 325W |
| Max. Power | 315W | 320W | 325W |
| Open Circuit Voltage | 40.53V | 40.79V | 41.05V |
| Short Circuit Current | 10.01A | 10.09A | 10.16A |
| Max. Power Voltage | 33.23V | 33.49V | 33.75V |
| Max. Power Current | 9.48A | 9.56A | 9.63A |
| Efficiency² | 18.9% | 19.2% | 19.5% |
