YE Mono 430W-445W 144 Half-Cell

Parameter

MECHANICAL SPECIFICATION
Module Dimensions	2011mm x 1046mm x 30mm（83.00 x 41.18 x 1.18 inches）
Weight	22.7kg(63.1 lb）
Cell	144(6 x 24) monocrystalline cells
Junction Box	IP68 rated
Front Glass	2.00mm (0.08 inches),Hight Transmission ,AR Coated Heat Strengthened Glass
Encapsulant material	POE/EVA
Back Glass	2.00mm (0.08 inches),Hight Transmission ,AR Coated Heat Strengthened Glass(Wite Grid Glass)
Frame	30mm (1.18 inches),Anodized Aluminium Alloy
Cables	photovoltain Technology Cable 4.00mm²(0.006 inches²)
Connector	MC4EV02/TS4*

Categories: Hot selling, Yanger MONO

Description
Reviews (0)

Description

ELECTRICAL CHARACTERISTICS
minimum performance at standard test conditions,stc1 (power tolerance -0~+5w)
Max. Power	430W	435W	440W	445W
Open Circuit Voltage	48.7V	48.9V	49.1V	49.3V
Short Circuit Current	11.20A	11.24A	11.28A	11.32A
Max. Power Voltage	40.5V	40.8V	41.1V	41.4V
Max. Power Current	10.62A	10.67A	10.71A	10.75A
Efficiency（%）	19.5%	19.7%	19.9%	20.2%
